Description
Vision Plus Status 350 Omni-Directional Digital Antenna TV Aerial for Caravan and Motorhome
We are authorised agents for Vision Plus and as such we offer the genuine product backed by the manufacturers full warranty.
Vision Plus’s most successful omni-directional antenna with its distinctive profile, high quality, powerful performance and versatility ensures it remains the market favourite.
Built for convenience and versatility, the antenna can be roof-mounted, mast-mounted, or installed using optional suction fittings. Its adjustable base allows level positioning on uneven surfaces, while the removable dome design makes storage and maintenance simple. Whilst the dome is removed, you can seal your caravan or motorhome with the Vision Plus blanking plate accessory (not included)
Features
- Designed for digital television signals and FM radio reception (on select models)
- Receives horizontal and vertical signals through 360 degrees
- Incorporates a power amplifier with variable gain adjustment (on select models)
- Standard fitting options, roof or mast mount with optional sucker mount
- Angle adjustable, allowing level mounting on a sloping surface
- Easily removable antenna dome
Available Variations
Choose the model that suits your setup:
• Status 350 TV Only – 1m (VP2 Amplifier)
- Designed for digital TV reception (UHF)
- Ideal for standard Freeview setups
- Cost-effective solution for TV-only use
• Status 350 TV + Radio – 1m (VP3 Amplifier)
- Enhanced signal amplification with variable gain control
- Improved performance in low-signal areas
- Suitable for more demanding installations
- Receives radio as well as TV reception
- Popular upgrade option for caravans and motorhomes
• Status 350 TV Only – 10m (VP2 Amplifier)
- Designed for digital TV reception (UHF)
- Ideal for standard Freeview setups
- Cost-effective solution for TV-only use
- Extra cable length for flexible installing
• Status 350 TV + Radio – 10m (VP3 Amplifier)
- Enhanced signal amplification with variable gain control
- Improved performance in low-signal areas
- Suitable for more demanding installations
- Receives radio as well as TV reception
- Popular upgrade option for caravans and motorhomes
- Extra cable length for flexible installing
Dimensions
VP2 Amplifier: 115mm x 45mm x 29mm
In stock for immediate dispatch with full VAT receipt and full manufacturer warranty.
Specifications
| Specification | Details |
|---|---|
| Amplifier Gain | 15 dB |
| Gain Adjustment | 0 – 15 dB |
| Gain Flatness | ±1.5 dB |
| Noise Figure | < 2.2 dB |
| Output Impedance | 75 Ω |
| Signal Handling | 80 dBµV |
| Power Supply | 10.8 – 28 V DC |
| Power Consumption | 55 mA |
| TV Lead Length | 1.5 metres |
Dimensions
| Specification | Details |
|---|---|
| Antenna Dome Diameter | 315 mm |
| Mounting Foot Diameter | 185 mm |
| Overall Height | 180 mm |
| Height (Without Dome) | 50 mm |
